| Number of inputs and outputs |
Number of analog outputs: 2 |
| System |
gold-plated contacts |
| Operating voltage |
12...30 DC |
| Protection class |
III |
| Reverse polarity protection |
yes |
| Power-on delay time |
< 1 |
| Measuring principle |
capacitive |
| Number of inputs and outputs |
Number of analog outputs: 2 |
| Total number of outputs |
2 |
| Output signal |
analog signal |
| Number of analog outputs |
2 |
| Analog current output |
4...20 |
| Max. load |
(Ub - 12 V) / 20 mA |
| Measuring range |
0...100 |
| Response time |
< 300; (T90) |
| Accuracy |
4; (in the range 20...80 % RH) |
| Resolution |
0,1 |
| Response time |
< 30; (T90) |
| Ambient temperature |
-40...70 |
| Note on ambient temperature |
| application humidity: ≤ 90 % RH | | non condensing |
|
| Storage temperature |
-40...85 |
| Note on storage temperature |
| storage humidity: ≤ 90 % RH | | non condensing |
|
| Protection |
IP 20; (only sensor: IP 57) |
| EMC |
| DIN EN 61000-6-2 | | | DIN EN 61000-6-4 | |
|
| MTTF |
178 |
| UL approval |
|
| Weight |
72.3 |
| Type of mounting |
Mounting on DIN rail and panel; (TH35 (EN 60715) / M5) |
| Dimensions |
140 x 40 x 38 |
| Material |
plastics UL94 V-0; light grey |
| Mounting orientation |
vertical; connector facing upwards |
| Pack quantity |
1 pcs. |
| Connection |
Connector: 1 x M12 (EN 61067-2-101); coding: A; Contacts: gold-plated |
