| Operating voltage |
8...32 DC |
| Reverse polarity protection |
yes |
| Total number of inputs and outputs |
16 |
| Number of inputs and outputs |
Number of digital inputs: 16; Number of analog inputs: 8; Number of frequency inputs: 4; Number of resistor inputs: 4 |
| Total number of inputs |
16 |
| Number of frequency inputs |
4 |
| Number of resistor inputs |
4 |
| Number of digital inputs |
16 |
| Number of analog inputs |
8 |
| Analog input (current) |
0...20 |
| Analog input (voltage) |
0...32 |
| Short-circuit protection |
yes |
| PLC function to IEC 61131-3 |
yes |
| Number of CAN interfaces |
2 |
| Ambient temperature |
-40...85 |
| Storage temperature |
-40...85 |
| Protection |
IP 65; IP 67 |
| EMC |
| DIN EN 61000-6-2 | | | DIN EN 61000-6-4 | |
|
| MTTF |
100 |
| Weight |
692 |
| Housing |
rectangular |
| Type of mounting |
Backplane mounting |
| Dimensions |
234.2 x 76 x 40.5 |
| Material |
PA reinforced glass-fiber |
| Display |
| 10-segment LED display, red/green 4-digit |
|
| Pack quantity |
1 pcs. |
| CAN IN |
Connector: 2 x DEUTSCH connector |
| Con. 1...8 |
Connector: 8 x DEUTSCH connector |
| X1 |
Connector: 1 x AMP connector |
