| Electrical design |
PNP/NPN |
| Output function |
normally open / closed; (configurable) |
| Sensing range |
10 |
| Communication interface |
IO-Link |
| Housing |
Threaded type |
| Dimensions |
M30 x 1.5 / L = 92.3 |
| Application |
simple evaluation of rotating and linear movement with regard to underspeed; blocking |
| Nominal voltage DC |
10...36 |
| Current consumption |
< 22 |
| Protection class |
III |
| Reverse polarity protection |
yes |
| Electrical design |
PNP/NPN |
| Output function |
normally open / closed; (configurable) |
| Max. voltage drop switching output DC |
2.5 |
| Permanent current rating of switching output DC |
250 |
| Short-time current rating of switching output |
250 |
| Short-circuit proof |
yes |
| Overload protection |
yes |
| Sensing range |
10 |
| Sensing range adjustable |
no |
| Operating distance |
0...8.1 |
| Setting range |
5...3600 |
| Measuring principle |
inductive |
| Correction factor |
steel: 1 / stainless steel: 0.7 / brass: 0.5 / aluminum: 0.4 / copper: 0.3 |
| Hysteresis |
10 |
| Start-up delay |
0...30 |
| Max. damping frequency |
18000 |
| Adjustment of the switch point |
Multiturn potentiometer or IO-Link |
| Communication interface |
IO-Link |
| Transmission type |
COM2 (38,4 kBaud) |
| Profiles |
| Smart Sensor - SSP 0 | Generic Profiled Sensor | | Function | Device identification | | Function | Multiple switching signal | | Function | Process data variable | | Function | Device diagnosis | | Function | Teach channel |
|
| Min. process cycle time |
3.2 |
| Supported DeviceIDs |
| Type of operation | DeviceID |
|---|
| default | 734 |
|
| Ambient temperature |
-25...60 |
| Storage temperature |
-25...60 |
| Protection |
IP 65; IP 67 |
| Approval |
IECEx BVS 17.0094X |
| ATEX marking |
II 3D Ex tc IIIC T80°C Dc X |
| EMC |
|
| Shock resistance |
|
| Vibration resistance |
|
| MTTF |
656 |
| Weight |
268 |
| Housing |
Threaded type |
| Mounting |
flush mountable |
| Dimensions |
M30 x 1.5 / L = 92.3 |
| Thread designation |
M30 x 1.5 |
| Material |
housing: brass special coating; PA; stainless steel; TPE-U |
| Display |
| Switching status | 1 x LED, green | | input signal | 1 x LED, yellow |
|
| Items supplied |
|
| Pack quantity |
1 pcs. |
| Connection |
Connector: 1 x M12; coding: A |
