| Type of light |
Infrared light |
| Housing |
Threaded type |
| Operating voltage |
10...55 DC |
| Current consumption |
30; ((24 V)) |
| Protection class |
II |
| Reverse polarity protection |
yes |
| Type of light |
Infrared light |
| Wave length |
880 |
| Electrical design |
PNP |
| Output function |
light-on/dark-on mode; (programmable) |
| Max. voltage drop switching output DC |
2.5 |
| Permanent current rating of switching output DC |
250 |
| Switching frequency DC |
100 |
| Short-circuit protection |
yes |
| Type of short-circuit protection |
yes (non-latching) |
| Overload protection |
yes |
| Range |
< 70 |
| Range adjustable |
yes |
| Ambient temperature |
-25...80 |
| Protection |
IP 65 |
| EMC |
|
| MTTF |
659 |
| Weight |
125.5 |
| Housing |
Threaded type |
| Dimensions |
M30 x 1.5 / L = 125 |
| Thread designation |
M30 x 1.5 |
| Number of channels |
1 |
| Material |
PBT; PPO modified |
| Lens material |
|
| Display |
| Switching status | 1 x LED, yellow |
|
| Items supplied |
|
| Remarks |
| light-on mode corresponds to the NC output function for through-beam fibers | | corresponds to the NO output function for diffuse-reflection fibers | | dark-on mode corresponds to the NO output function for through-beam fibers | | corresponds to the NC output function for diffuse-reflection fiber optics |
|
| Pack quantity |
1 pcs. |
| Connection |
terminals: ...1.5 mm²; Cable sheath: Ø 7...13 mm; Cable gland: M20 X 1.5 |
