| Electrical design |
NAMUR |
| Output function |
normally closed |
| Housing |
rectangular |
| Dimensions |
19 x 10 x 15 |
| Connection at circuit amplifier |
yes |
| Switching amplifiers |
connection to certified intrinsically safe circuits with the max. values: U = 15 V / I = 50 mA / P = 120 mW |
| Nominal voltage DC |
8.2; (1kΩ) |
| Supply voltage DC |
5...25; (when used outside the hazardous area) |
| Current consumption |
< 1.2; (disabled; conductive: > 2,1) |
| Protection class |
III |
| Electrical design |
NAMUR |
| Output function |
normally closed |
| Switching frequency DC |
3000 |
| Insertion depth (from the side) |
5...7 |
| Hysteresis |
0...0.05 |
| Ambient temperature |
-40...100 |
| Protection |
IP 67 |
| Approval |
BVS 08 ATEX E026; IECEx BVS 09.0016 |
| ATEX marking |
II 1G Ex ia IIC T4 Ga |
|
II 1D Ex ia IIIC T125°C Da |
| EMC |
|
| MTTF |
2942 |
| Max. internal capacitance |
150 |
| Max. internal inductance |
150 |
| Weight |
34 |
| Housing |
rectangular |
| Dimensions |
19 x 10 x 15 |
| Slot width |
3.5 |
| Material |
PBT |
| Items supplied |
| counter-sunk screw: 1 x (M1,6 x 10 mm), stainless steel | | Hexagon nut: 1 x M1,6 |
|
| Pack quantity |
1 pcs. |
| Connection |
Connector: 1 x DUBOX |
