| Electrical design |
PNP/NPN |
| Output function |
normally open |
| Sensing range |
50 |
| Housing |
rectangular |
| Dimensions |
92 x 80 x 40 |
| Operating voltage |
10...55 DC |
| Protection class |
II |
| Reverse polarity protection |
yes |
| Electrical design |
PNP/NPN |
| Output function |
normally open |
| Max. voltage drop switching output DC |
4.6 |
| Minimum load current |
4 |
| Max. leakage current |
0.6 |
| Permanent current rating of switching output DC |
400 |
| Switching frequency DC |
90 |
| Short-circuit protection |
yes |
| Type of short-circuit protection |
yes (non-latching) |
| Overload protection |
yes |
| Sensing range |
50 |
| Operating distance |
0...40.5; (mounted flush with mild steel (ST37)) |
| Correction factor |
steel: 1 / stainless steel: 0.7 / brass: 0.4 / aluminum: 0.3 / copper: 0.2 |
| Hysteresis |
3...20 |
| Switch-point drift |
-15...15 |
| Ambient temperature |
-25...70 |
| Protection |
IP 67 |
| EMC |
| EN 60947-5-2 | | | EN 55011 | class B |
|
| MTTF |
1631 |
| Weight |
399 |
| Housing |
rectangular |
| Mounting |
flush mountable |
| Type of mounting |
Mounting on DIN rail; (TH35 (EN 60715)) |
| Dimensions |
92 x 80 x 40 |
| Material |
PPE; brass nickel-plated |
| Display |
| Switching status | 1 x LED, red |
|
| Items supplied |
|
| Pack quantity |
1 pcs. |
| Connection |
Connector: 1 x M12; coding: A |
