| Electrical design |
PNP/NPN |
| Output function |
normally open / closed; (selectable) |
| Sensing range |
20 |
| Housing |
tubular |
| Dimensions |
Ø 34 / L = 98 |
| Operating voltage |
10...55 DC |
| Protection class |
II |
| Reverse polarity protection |
yes |
| Electrical design |
PNP/NPN |
| Output function |
normally open / closed; (selectable) |
| Max. voltage drop switching output DC |
4.6 |
| Minimum load current |
4 |
| Max. leakage current |
1 |
| Permanent current rating of switching output DC |
300 |
| Switching frequency DC |
300 |
| Short-circuit protection |
yes |
| Type of short-circuit protection |
yes (non-latching) |
| Overload protection |
yes |
| Sensing range |
20 |
| Real sensing range Sr |
20 ± 10 % |
| Operating distance |
0...16.2 |
| Correction factor |
steel: 1 / stainless steel: 0.7 / brass: 0.4 / aluminum: 0.3 / copper: 0.2 |
| Hysteresis |
1...15 |
| Switch-point drift |
-10...10 |
| Ambient temperature |
-25...80 |
| Protection |
IP 65 |
| EMC |
| EN 60947-5-2 | | | EN 55011 | class B |
|
| MTTF |
1647 |
| UL approval |
| Ta | 0...40 °C | | Enclosure type | Type 1 | | File number UL | E174191 |
|
| Weight |
183 |
| Housing |
tubular |
| Mounting |
non-flush mountable |
| Dimensions |
Ø 34 / L = 98 |
| Material |
PBT; bevelled housing part: PC |
| Display |
| Switching status | 1 x LED, yellow |
|
| Items supplied |
|
| Pack quantity |
1 pcs. |
| Connection |
terminals: ...2.5 mm²; Cable sheath: Ø 7...13 mm; Cable gland: M20 X 1.5 |
