| Electrical design |
PNP/NPN |
| Output function |
normally open |
| Sensing range |
10 |
| Housing |
tubular |
| Dimensions |
Ø 20 / L = 80 |
| Operating voltage |
10...55 DC |
| Protection class |
II |
| Reverse polarity protection |
yes |
| Electrical design |
PNP/NPN |
| Output function |
normally open |
| Max. voltage drop switching output DC |
4.6 |
| Minimum load current |
4 |
| Max. leakage current |
0.8 |
| Permanent current rating of switching output DC |
400 |
| Switching frequency DC |
500 |
| Short-circuit protection |
yes |
| Type of short-circuit protection |
yes (non-latching) |
| Overload protection |
yes |
| Sensing range |
10 |
| Real sensing range Sr |
10 ± 10 % |
| Operating distance |
0...8.1 |
| Correction factor |
steel: 1 / stainless steel: 0.7 / brass: 0.5 / aluminum: 0.4 / copper: 0.3 |
| Hysteresis |
3...15 |
| Switch-point drift |
-10...10 |
| Ambient temperature |
-25...80 |
| Protection |
IP 67 |
| EMC |
| EN 60947-5-2 | | | EN 55011 | class B |
|
| MTTF |
1862 |
| Weight |
340 |
| Housing |
tubular |
| Mounting |
non-flush mountable |
| Dimensions |
Ø 20 / L = 80 |
| Material |
PBT |
| Display |
| Switching status | 1 x LED, red |
|
| Items supplied |
|
| Pack quantity |
1 pcs. |
| Connection |
Cable: 6 m, PVC; 2 x 0.5 mm² |
