| Output function |
normally open |
| Sensing range |
10 |
| Housing |
tubular |
| Dimensions |
Ø 20 / L = 77 |
| Operating voltage |
20...250 AC/DC |
| Protection class |
II |
| Reverse polarity protection |
no |
| Output function |
normally open |
| Max. voltage drop switching output DC |
6 |
| Max. voltage drop switching output AC |
6.5 |
| Minimum load current |
5 |
| Max. leakage current |
2.5 (250 V AC) / 1.3 (110 V AC) / 0.8 (24 V DC) |
| Permanent current rating of switching output AC |
250; (350 (...50 °C)) |
| Permanent current rating of switching output DC |
100 |
| Short-time current rating of switching output |
2200; (20 ms / 0,5 Hz) |
| Switching frequency AC |
25 |
| Switching frequency DC |
70 |
| Short-circuit proof |
no |
| Overload protection |
no |
| Sensing range |
10 |
| Real sensing range Sr |
10 ± 10 % |
| Operating distance |
0...8.1 |
| Correction factor |
steel: 1 / stainless steel: 0.7 / brass: 0.4 / aluminum: 0.3 / copper: 0.2 |
| Hysteresis |
1...15 |
| Switch-point drift |
-10...10 |
| Ambient temperature |
-25...80 |
| Protection |
IP 67 |
| EMC |
|
| MTTF |
603 |
| UL approval |
| Ta | 0...40 °C | | Enclosure type | Type 1 | | File number UL | E174191 |
|
| Weight |
153 |
| Housing |
tubular |
| Mounting |
non-flush mountable |
| Dimensions |
Ø 20 / L = 77 |
| Material |
PBT |
| Display |
| Switching status | 1 x LED, red |
|
| Connection |
Cable: 2 m, PVC; 2 x 0.5 mm² |
| Items supplied |
|
| Remarks |
| Recommendation: check the unit for reliable function after a short circuit. |
|
| Pack quantity |
1 pcs. |
