| Measuring range |
1...25 |
| Process connection |
threaded connection Rp 3/4 Internal thread |
| Media |
Liquids; water; glycol solutions; Coolants |
| Medium temperature |
-10...100 |
| Pressure rating |
|
| Operating voltage |
18...32 DC; (to SELV/PELV) |
| Current consumption |
< 35 |
| Protection class |
III |
| Reverse polarity protection |
yes |
| Output signal |
analog signal |
| Analog current output |
4...20 |
| Max. load |
500 |
| Short-circuit protection |
yes |
| Overload protection |
yes |
| Measuring range |
1...25 |
| Repeatability |
1 |
| Measuring error |
± 5 |
| Response time |
< 0.01 |
| Ambient temperature |
0...60 |
| Storage temperature |
-15...80 |
| Protection |
IP 65; IP 67 |
| EMC |
| DIN EN 61000-6-2 | | | DIN EN 61000-6-3 | |
|
| Shock resistance |
| DIN EN 60068-2-27 | 20 g (11 ms) |
|
| Vibration resistance |
| DIN EN 60068-2-6 | 5 g (10...2000 Hz) |
|
| MTTF |
778 |
| Weight |
556.65 |
| Material |
brass chemically nickel-plated; PP; stainless steel (1.4404 / 316L); aluminum anodized; PA |
| Materials (wetted parts) |
stainless steel (1.4401 / 316); brass; brass chemically nickel-plated; PP; PPS; O-ring: FKM |
| Process connection |
threaded connection Rp 3/4 Internal thread |
| Switching cycles mechanical |
10 million |
| Remarks |
| Recommendation Use 200 micron filtration | | All data refer to water (20 °C). |
|
| Notes |
Please note the changed housing design! |
| Pack quantity |
1 pcs. |
| Connection |
Connector: 1 x M12; coding: A |
