| Probe length L |
12 |
| Process connection |
threaded connection G 1/2 external thread |
| Media |
Liquids; Gases |
| Medium temperature |
-20...70 |
| Pressure rating |
|
| Response time |
1...10 |
| Response time |
1...10 |
| Connection to control monitor |
VS2000 Exi (PTB 01 ATEX 2075) |
| Probe length L |
12 |
| Max. temperature gradient of medium |
15 |
| Response time |
1...10 |
| Ambient temperature |
-20...70 |
| Protection |
IP 67 |
| Approval |
DMT 03 ATEX E091; IECEX BVS 06.0007 |
| ATEX marking |
II 2G Ex ia IIC T4 Gb |
| Shock resistance |
| DIN IEC 68-2-27 | 40 g (11 ms) |
|
| Vibration resistance |
| DIN IEC 68-2-6 | 10 g (55...2000 Hz) |
|
| MTTF |
8648 |
| Max. internal capacitance |
0.4 |
| Max. internal inductance |
2 |
| Temperature class |
T4 |
| Weight |
218.5 |
| Housing |
tubular |
| Material |
stainless steel (1.4404 / 316L) |
| Materials (wetted parts) |
stainless steel (1.4404 / 316L) |
| Process connection |
threaded connection G 1/2 external thread |
| Probe diameter |
7.7 |
| Installation length EL |
45 |
| Remarks |
| In principle, the type test according to 94/9/EC (ATEX) only takes atmospheric conditions into account (0.8...1.1 bar). | | For pressures outside this range use must be assessed and approved by the user. | | Adhere to the operating instructions and the type test certificate. |
|
| Pack quantity |
1 pcs. |
| Connection |
Connector: 1 x M12; coding: A; Maximum cable length: 100 m |
