| Output function |
normally open / closed; (selectable) |
| Sensing range |
5...40; (Programming buttons) |
| Housing |
Threaded type |
| Dimensions |
M30 x 1.5 / L = 90 |
| Installation |
detection through non-metallic container wall or on bypass pipes |
| Media |
dry bulk material; liquids |
| Frequency AC |
47...63 |
| Operating voltage |
30...250 AC / 20...250 DC |
| Protection class |
II |
| Reverse polarity protection |
yes |
| Measuring principle |
capacitive |
| Output function |
normally open / closed; (selectable) |
| Max. voltage drop switching output DC |
8 |
| Max. voltage drop switching output AC |
10 |
| Max. leakage current |
2.5 (250 V AC) / 1.7 (110 V AC) / 1.5 (24 V DC) |
| Permanent current rating of switching output AC |
100; (150 (...40 °C)) |
| Permanent current rating of switching output DC |
100; (150 (...40 °C)) |
| Short-time current rating of switching output |
1000; (20 ms / 0,5 Hz) |
| Switching frequency AC |
10 |
| Switching frequency DC |
10 |
| Short-circuit proof |
no |
| Overload protection |
no |
| Sensing range |
5...40; (Programming buttons) |
| Sensing range adjustable |
yes |
| Factory setting sensing range |
20 |
| Real sensing range Sr |
20 ± 10 % |
| Correction factor |
glass: 0.3 / water: 1 / ceramics: 0.2 / PVC: 0.1 |
| Hysteresis |
1...15 |
| Switch-point drift |
-20...20 |
| Ambient temperature |
-25...80 |
| Note on ambient temperature |
| temperature of the sensing face: -25...110 °C |
|
| Protection |
IP 65; IP 67 |
| EMC |
|
| MTTF |
321 |
| Weight |
89.1 |
| Housing |
Threaded type |
| Mounting |
non-flush mountable |
| Dimensions |
M30 x 1.5 / L = 90 |
| Thread designation |
M30 x 1.5 |
| Material |
housing: PBT; Pushbuttons: TPE-U; LED window: PC |
| Display |
| Switching status | 1 x LED ring, yellow translucent connector indicates output status |
|
| Teach function |
yes |
| Electronic lock |
yes |
| Required protection |
miniature fuse to IEC60127-2 sheet 1; ≤ 2 A; fast acting |
| Items supplied |
|
| Remarks |
| Note: | | Check the safe functioning of the unit after a short circuit. |
|
| Pack quantity |
1 pcs. |
|
Connector: 1 x 1/2"; coding: C |
