| Output function |
normally open / closed; (selectable) |
| Sensing range |
15 |
| Housing |
Threaded type |
| Dimensions |
M30 x 1.5 / L = 92 |
| Operating voltage |
20...250 AC/DC |
| Reverse polarity protection |
no |
| Output function |
normally open / closed; (selectable) |
| Max. voltage drop switching output DC |
8 |
| Max. voltage drop switching output AC |
10 |
| Minimum load current |
5 |
| Max. leakage current |
2.5 (250 V AC) / 1.7 (110 V AC) / 1.5 (24 V DC) |
| Permanent current rating of switching output AC |
200; (250 (...50 °C)) |
| Permanent current rating of switching output DC |
200; (250 (...50 °C)) |
| Short-time current rating of switching output |
1500; (20 ms / 0,5 Hz) |
| Switching frequency AC |
25 |
| Switching frequency DC |
40 |
| Short-circuit proof |
no |
| Overload protection |
no |
| Sensing range |
15 |
| Real sensing range Sr |
15 ± 10 % |
| Operating distance |
0...12.1 |
| Correction factor |
glass: 0.4 / water: 1 / ceramics: 0.2 / PVC: 0.2 |
| Hysteresis |
1...15 |
| Switch-point drift |
-15...15 |
| Ambient temperature |
-20...70 |
| Protection |
IP 65 |
| Increased immunity |
yes; (Increased immunity to conducted radio frequency interference) |
| EMC |
|
| MTTF |
293 |
| Weight |
104 |
| Housing |
Threaded type |
| Mounting |
non-flush mountable |
| Dimensions |
M30 x 1.5 / L = 92 |
| Thread designation |
M30 x 1.5 |
| Material |
PBT |
| Display |
| Switching status | 1 x LED, yellow |
|
| Required protection |
miniature fuse to IEC60127-2 sheet 1; ≤ 2 A; fast acting |
| Items supplied |
|
| Remarks |
| Recommendation: check the unit for reliable function after a short circuit. |
|
| Pack quantity |
1 pcs. |
| Connection |
Connector: 1 x valve plug type A DIN (DIN EN 175301-803) |
