| Number of inputs and outputs |
Number of digital outputs: 1 |
| System |
gold-plated contacts |
| Operating voltage |
18...30 DC |
| Current consumption |
13 |
| Protection class |
III |
| Reverse polarity protection |
yes |
| Power-on delay time |
< 1 |
| Measuring principle |
capacitive |
| Number of inputs and outputs |
Number of digital outputs: 1 |
| Total number of outputs |
1 |
| Output signal |
IO-Link |
| Number of digital outputs |
1 |
| Measuring range |
0...100 |
| Response time |
< 300; (T90) |
| Accuracy |
3; (in the range 20...80 % RH) |
| Resolution |
0,1 |
| Response time |
< 30; (T90) |
| Communication interface |
IO-Link |
| Transmission type |
COM2 (38,4 kBaud) |
| IO-Link revision |
1.1 |
| Profiles |
| Common - I&D | Identification and Diagnosis | | Function | Measurement data, standard resolution |
|
| SIO mode |
no |
| Required master port class |
A |
| Min. process cycle time |
4.5 |
| Supported DeviceIDs |
| Type of operation | DeviceID |
|---|
| default | 1337 |
|
| Ambient temperature |
-40...80 |
| Note on ambient temperature |
| application humidity: ≤ 90 % RH | | non condensing |
|
| Storage temperature |
-40...85 |
| Note on storage temperature |
| storage humidity: ≤ 90 % RH | | non condensing |
|
| Protection |
IP 20; (only sensor: IP 57) |
| EMC |
| DIN EN 61000-6-2 | | | DIN EN 61000-6-4 | |
|
| MTTF |
195 |
| UL approval |
|
| Weight |
70 |
| Type of mounting |
Mounting on DIN rail and panel; (TH35 (EN 60715) / M5) |
| Dimensions |
140 x 40 x 38 |
| Material |
plastics UL94 V-0; light grey |
| Mounting orientation |
vertical; connector facing upwards |
| Pack quantity |
1 pcs. |
| Connection |
Connector: 1 x M12 (EN 61067-2-101); coding: A; Contacts: gold-plated |
