| Image resolution |
1280 x 800 |
| Image resolution 3D |
640 x 480 |
| Angle of aperture |
128 x 80 |
| Angle of aperture 3D |
64 x 50 |
| Image repetition frequency |
20 |
| Image repetition frequency 3D |
10 |
| Operating voltage |
19.2...28.8 DC |
| Max. current consumption |
800 |
| Power consumption |
8.6; ((FPS x 0,32) + 2,2; FPS = Framerate Head) |
| Image sensor |
PMD 3D ToF-Chip / 2D Chip |
| Integrated lighting |
yes; (infrared: 940 nm invisible radiation) |
| Image resolution |
1280 x 800 |
| Image resolution 3D |
640 x 480 |
| Angle of aperture |
128 x 80 |
| Angle of aperture 3D |
64 x 50 |
| Image repetition frequency |
20 |
| Image repetition frequency 3D |
10 |
| Transmission standard |
FPD-Link |
| Type of connector |
HFM (Mini-Fakra) |
| Ambient temperature |
-10...40 |
| Storage temperature |
-40...85 |
| Protection |
IP 54 |
| EMC |
| EN IEC 61000-6-4 | radiation of interference / residential, commercial and light-industrial environments | | EN IEC 61000-6-2 | noise immunity / industrial environments |
|
| Shock resistance |
| EN 60068-2-27 | 50 g / (11 ms) not repetitive | | EN 60068-2-27 | 40 g / (6 ms) repetitive |
|
| Vibration resistance |
| EN 60068-2-6 | 2 g / (10...150 Hz) | | EN 60068-2-64 | 2.3 g RMS / (10...500 Hz) |
|
| Laser protection class |
1 |
| Notes on laser protection |
| Caution: | invisible laser radiation | | laser class: | 1 | | IEC 60825-1:2014 | | Complies with 21 CFR 1040.10 except for conformance with IEC 60825-1 Ed. 3, as described in Laser Notice No. 56, dated May 8, 2019. |
|
| Electrical safety |
| EN 61010-2-201 | electrical supply only via PELV circuits |
|
| Weight |
197.5 |
| Dimensions |
90 x 31 x 26 |
| Material |
housing: diecast zinc coated; Cover: PMMA; window: glass / PMMA; rear of the housing: aluminum coated |
| Tightening torque |
< 0.8 |
| Pack quantity |
1 pcs. |
|
Connector: 1 x Dual-HFM (AMK142-1M4Z5-A) |
