Compact SSR, 20A, 264 VAC max, zero cross over
Характеристики
| Application | ON/OFF control |
| Number of phases | 1 |
| Mounting method | Screw |
| Terminal type | Tab terminal |
| Complete with socket | No |
| LED indicator | No |
| Rated operational voltage, AC | 100-240 V |
| Operating voltage range, AC | 75-264 V |
| Rated operation current Ie at AC-1 | 20 A |
| Supply voltage DC | 19.2-28.8 V |
| Must operate voltage max. | 19.2 V |
| Must release voltage min. | 1 V |
| Maximum operating temperature | 80 °C |
| Minimum operating temperature | -30 °C |
| Isolation | Phototriac |
| Switching at zero-crossing | Yes |
Все характеристики
| Specifications | |
| Application | ON/OFF control |
| Number of phases | 1 |
| Mounting method | Screw |
| Terminal type | Tab terminal |
| Complete with socket | No |
| LED indicator | No |
| Rated operational voltage, AC | 100-240 V |
| Operating voltage range, AC | 75-264 V |
| Rated operation current Ie at AC-1 | 20 A |
| Supply voltage DC | 19.2-28.8 V |
| Must operate voltage max. | 19.2 V |
| Must release voltage min. | 1 V |
| Maximum operating temperature | 80 °C |
| Minimum operating temperature | -30 °C |
| Isolation | Phototriac |
| Switching at zero-crossing | Yes |
