Solid state relay, surface mounting, zero crossing, 1-pole, 50 A, 24 to 240 VAC
Характеристики
| Application | ON/OFF control |
| Number of phases | 1 |
| Mounting method | Screw |
| Terminal type | Screw |
| Complete with socket | No |
| LED indicator | No |
| Rated operational voltage, AC | 24-240 V |
| Operating voltage range, AC | 19-264 V |
| Rated operational voltage, DC | |
| Operating voltage range, DC | |
| Rated operation current Ie at AC-1 | 50 A |
| Product Height (unpacked) | 58 mm |
| Product Width (unpacked) | 43 mm |
| Product Depth (unpacked) | 27 mm |
| Supply voltage DC | |
| Supply voltage AC | 100-240 V |
| Control current max. | |
| Must operate voltage max. | 75 V |
| Must release voltage min. | 20 V |
| Maximum operating temperature | 80 °C |
| Minimum operating temperature | -30 °C |
| Isolation | Photocoupler |
| Switching at zero-crossing | Yes |
Все характеристики
| Specifications | |
| Application | ON/OFF control |
| Number of phases | 1 |
| Mounting method | Screw |
| Terminal type | Screw |
| LED indicator | No |
| Rated operational voltage, AC | 24-240 V |
| Operating voltage range, AC | 19-264 V |
| Rated operation current Ie at AC-1 | 50 A |
| Product Height (unpacked) | 58 mm |
| Product Width (unpacked) | 43 mm |
| Product Depth (unpacked) | 27 mm |
| Supply voltage AC | 100-240 V |
| Must operate voltage max. | 75 V |
| Must release voltage min. | 20 V |
| Maximum operating temperature | 80 °C |
| Minimum operating temperature | -30 °C |
| Switching at zero-crossing | Yes |
