| Number of inputs and outputs |
Number of analog outputs: 1 |
| Measuring range |
|
| Process connection |
threaded connection G 1/4 external thread |
| Installation length EL |
25 |
| Measuring element |
1 x Pt 1000; (to DIN EN 60751, class A) |
| Media |
liquids and gases |
| Pressure rating |
400 |
| Operating voltage |
8...32 DC; (cULus - Class 2 source required) |
| Current consumption |
< 30 |
| Protection class |
III |
| Reverse polarity protection |
yes |
| Number of inputs and outputs |
Number of analog outputs: 1 |
| Total number of outputs |
1 |
| Output signal |
analog signal |
| Number of analog outputs |
1 |
| Analog voltage output |
0.5...4.5 |
| Min. load resistance |
2000 |
| Short-circuit protection |
yes |
| Overload protection |
yes |
| Probe length L |
13 |
| Measuring range |
|
| Resolution of analog output |
0.1 |
| Precision analog output |
± 0,3 + (± 0,1 % MS) |
| Temperature coefficient |
0,1; (In case of deviation from the reference condition 25 ± 5 °C) |
| Dynamic response T05 / T09 |
1 / 3; (according to DIN EN 60751) |
| Ambient temperature |
-40...100 |
| Storage temperature |
-40...100 |
| Protection |
IP 68; IP 69K |
| EMC |
| DIN EN 61000-6-2 | | | DIN EN 61000-6-3 | |
|
| Shock resistance |
| DIN EN 60068-2-27 | 50 g (11 ms) |
|
| Vibration resistance |
| DIN EN 60068-2-6 | 20 g (10...2000 Hz) |
|
| MTTF |
849 |
| UL approval |
|
| Weight |
90.5 |
| Housing |
tubular |
| Dimensions |
Ø 21.8 / L = 84.8 |
| Material |
stainless steel (1.4404 / 316L); PPS; FKM |
| Materials (wetted parts) |
stainless steel (1.4404 / 316L); FKM |
| Process connection |
threaded connection G 1/4 external thread |
| Probe diameter |
6 |
| Installation length EL |
25 |
| Remarks |
| The values for accuracy apply to flowing water. | | referring to UL: for use on a low voltage circuit with overcurrent protection | | in accordance with UL873 tab. 28.1 or Imax = 100/Ub (Ub = voltage of the circuit) |
|
| Pack quantity |
1 pcs. |
| Connection |
Connector: 1 x AMP-Superseal |
