| Operating voltage |
12...27 DC |
| Current consumption |
11...48 |
| Communication interface |
CAN |
| Number of CAN interfaces |
2 |
| Transmission rate |
250 (125...1000) kBaud |
| Interface |
CAN Interface 2.0 A/B ISO 11898 |
| Terminating resistor |
yes; (internal ; 120 Ohm; cannot be deactivated) |
| Transmission rate |
250 kBaud |
| Interface |
CAN Interface ISO 11783 |
| Terminating resistor |
no |
| Ambient temperature |
-40...80 |
| Protection |
IP 67 |
| Weight |
190.1 |
| Housing |
rectangular |
| Type of mounting |
panel/surf. |
| Dimensions |
72 x 120 x 29 |
| Material |
housing: PA 12 black |
| Display |
| status | 1 x LED, green/red | | supply voltage | 1 x LED, green/red |
|
| Processor |
ARM Cortex M4 32 bit |
| Program memory |
1,5 MB Flash |
| Working memory |
RAM: 320 kB
FRAM: 16 kB |
| Pack quantity |
1 pcs. |
|
Connector: 1 x M12; coding: A |
|
Connector: 1 x M12; coding: A |
