| Operating voltage |
8...32 DC |
| Total number of inputs and outputs |
32 |
| Number of inputs and outputs |
Number of digital inputs: 16; Number of analog inputs: 4; Number of frequency inputs: 4; Number of resistor inputs: 2; Number of digital outputs: 16; Number of analog outputs: 2 |
| Number of frequency inputs |
4 |
| Number of resistor inputs |
2 |
| Number of digital inputs |
16 |
| Number of analog inputs |
4 |
| Analog input (current) |
0...20 |
| Analog input (voltage) |
0...32 |
| Number of digital outputs |
16 |
| Number of analog outputs |
2 |
| Analog voltage output |
0.2...10 |
| Number of PWM outputs |
12 |
| Number of PWM-I outputs |
2 |
| Parameter setting options |
input/output functions |
| PLC function to IEC 61131-3 |
yes |
| Number of CAN interfaces |
2 |
| MTTF |
91 |
| Weight |
1129.5 |
| Housing |
rectangular |
| Type of mounting |
screw mounting |
| Dimensions |
153 x 147 x 43 |
| Pack quantity |
1 pcs. |
