| Product characteristics |
|
| Measuring range of vibration |
0...25 |
| Frequency range |
10...1000 |
| Application |
|
| Application |
Vibration sensor to ISO 10816 |
| Radio approval for |
USA; Canada; EU/RED; Australia; Brazil |
| Note on radio approval |
<table><tr><td>The list of countries applying the European Radio Equipment Directive 2014/53/EU (RED) can be found under “Downloads”. </td></tr></table> |
| Electrical data |
|
| Operating voltage |
3.6 DC; (lithium thionyl chloride battery; battery life: > 4 years battery cannot be replaced) |
| Protection class |
III |
| Type of sensor |
Microelectromechanical system (MEMS) |
| Measuring/setting range |
|
| Measuring range of vibration |
0...25 |
| Frequency range |
10...1000 |
| Number of measurement axes |
1 |
| Temperature measurement |
|
| Measuring range |
-30...80 |
| Resolution |
0.1 |
| Accuracy / deviations |
|
| Accuracy |
≤ 10 % |
| Linearity deviation |
≤ 10 % |
| Software / programming |
|
| Parameter setting options |
MQTT |
| Interfaces |
|
| Frequency band |
2,4 GHz ISM |
| Range |
< 25 m |
| Safety standard |
AES-128 |
| Protocol |
proprietary |
| Operating conditions |
|
| Ambient temperature |
-30...80 |
| Note on ambient temperature |
<table><tr><td>-20...55 °C recommended temperature for maximum battery life</td></tr></table> |
| Storage temperature |
-30...80 |
| Protection |
IP 68 |
| Tests / approvals |
|
| EMC |
<table><tr><td>DIN EN 61000-6-2</td><td></td></tr><tr><td>DIN EN 301489-1</td><td></td></tr><tr><td>DIN EN 301489-17</td><td></td></tr></table> |
| Mechanical data |
|
| Weight |
177.1 |
| Type of mounting |
set screw; (M8) |
| Material |
housing: stainless steel (1.4404 / 316L); polyethylene |
| Tightening torque |
8 |
| Accessories |
|
| Items supplied |
<table><tr><td>Mounting adapter</td></tr></table> |
| Remarks |
|
| Pack quantity |
1 pcs. |
