| Product characteristics |
|
| Measuring range of vibration |
-80...80; (-50...50 g when connected to a VSE) |
| Frequency range |
1.5...16000 |
| Measuring principle |
piezoelectric |
| Communication interface |
IEPE |
| Application |
|
| Design |
for connection to external diagnostic electronics VSE |
| Electrical data |
|
| Bias voltage DC |
10...12 |
| Current consumption |
0.5...8 |
| Min. insulation resistance |
100; (500 V DC) |
| Reverse polarity protection |
yes |
| Measuring/setting range |
|
| Measuring range of vibration |
-80...80; (-50...50 g when connected to a VSE) |
| Frequency range |
1.5...16000 |
| Measuring principle |
piezoelectric |
| Noise density |
0.1 |
| Max. transverse sensitivity |
5 |
| Minimum measuring time |
1 |
| Number of measurement axes |
1 |
| Accuracy / deviations |
|
| Accuracy |
± 10 % |
| Measuring sensitivity |
100 mV/g |
| Interfaces |
|
| Communication interface |
IEPE |
| Operating conditions |
|
| Ambient temperature |
-55...130 |
| Storage temperature |
-55...130 |
| Protection |
IP 67 |
| Tests / approvals |
|
| EMC |
<table><tr><td>EN 61326-1</td><td>: 2013</td></tr></table> |
| Shock resistance |
<table><tr><td>EN 61326-1</td><td>: 2013</td></tr></table> |
| MTTF |
1142 |
| Mechanical data |
|
| Weight |
135 |
| Type of mounting |
M8 x 1,25 |
| Material |
housing: stainless steel |
| Tightening torque |
8 |
| Remarks |
|
| Pack quantity |
1 pcs. |
| Electrical connection |
|
