Характеристики
| Pressure rating | 16 |
| Sensor connection | G 1/2; sealing cone; Ø 6 mm |
| Installation length EL | 94 |
| Process connection | 1/2" NPT |
| Bore length BL | 137 |
Все характеристики
| Design | for temperature sensors EL = 100 mm | ||
| Pressure rating |
|
||
| Weight | 164.6 | ||
| Material | stainless steel (1.4404 / 316L) | ||
| Sensor connection | G 1/2 sealing cone Ø 6 mm | ||
| Process connection | 1/2" NPT | ||
| Installation length EL | 94 | ||
| Bore length BL | 137 | ||
| Pack quantity | 1 pcs. |
Приемущества
| Reliable protection against aggressive media and high flow velocities |
| Allows the replacement of the temperature sensor in a running process |
| High pressure resistance |
| Simple process connection via adapter |
| Robust stainless steel housing for the requirements of harsh industrial environments |
