Характеристики
| Pressure rating | 100 |
| Sensor connection | G 1/2 |
| Process connection | Welding adapter Ø 30 mm |
Все характеристики
| Application | |
| Design | for temperature sensors EL = 200 mm |
| Pressure rating | <table><tr><td>100 bar</td><td>10 MPa</td></tr></table> |
| Measuring/setting range | |
| Probe length L | 173 |
| Mechanical data | |
| Weight | 505 |
| Dimensions | Ø 10 |
| Material | stainless steel (1.4571/316Ti ) |
| Sensor connection | G 1/2 |
| Process connection | Welding adapter Ø 30 mm |
| Surface characteristics Ra/Rz of the wetted parts | Ra < 0.6 µm |
| Remarks | |
| Pack quantity | 1 pcs. |
Приемущества
| Reliable protection against aggressive media and high flow velocities |
| Allows the replacement of the temperature sensor in a running process |
| High pressure resistance |
| Robust stainless steel housing for the requirements of harsh industrial environments |
