| Type of light |
red light |
| Laser protection class |
1 |
| Housing |
rectangular |
| Function principle |
Through-beam sensor |
| Operating voltage |
10...30 DC |
| Current consumption |
< 12 |
| Protection class |
III |
| Reverse polarity protection |
yes |
| Type of light |
red light |
| Wave length |
650 |
| Typ. lifetime |
50000 |
| Overload protection |
yes |
| Transmitter / receiver |
transmitter |
| Range |
< 15 |
| Range adjustable |
no |
| Max. light spot diameter |
24 |
| Light spot dimensions refer to |
at maximum range |
| Ambient temperature |
-10...60 |
| Protection |
IP 67 |
| EMC |
|
| Laser protection class |
1 |
| Notes on laser protection |
| Caution: | Laser light | | laser class: | 1 | | EN / IEC60825-1:2007 | | EN / IEC60825-1:2014 | | Complies with 21 CFR 1040.10 except for conformance with IEC 60825-1 Ed. 3, as described in Laser Notice No. 56, dated May 8, 2019. |
|
| MTTF |
918 |
| Weight |
27.9 |
| Housing |
rectangular |
| Dimensions |
35 x 24 x 11 |
| Material |
housing: ABS; LED window: SEPS; pushbutton: SEPS |
| Lens material |
|
| Lens alignment |
Front sensing |
| Display |
|
| Items supplied |
| screws: 2 | | spring washers: 2 | | Nuts: 2 |
|
| Remarks |
| cULus - Class 2 source required |
|
| Pack quantity |
1 pcs. |
| Connection |
Connector: 1 x M8; coding: A |
