| Product characteristics |
|
| Type of light |
Infrared light |
| Application |
|
| System |
Function check output |
| Electrical data |
|
| Operating voltage |
10...35 DC; (cULus - Class 2 source required) |
| Current consumption |
< 45 |
| Protection class |
III |
| Reverse polarity protection |
yes |
| Type of light |
Infrared light |
| Wave length |
870 |
| Outputs |
|
| Electrical design |
PNP |
| Output function |
dark-on mode |
| Max. voltage drop switching output DC |
2 |
| Function check output |
yes |
| Max. current load for function check output |
200 |
| Permanent current rating of switching output DC |
200 |
| Switching frequency DC |
200 |
| Short-circuit protection |
yes |
| Type of short-circuit protection |
yes (non-latching) |
| Overload protection |
yes |
| Operating conditions |
|
| Ambient temperature |
-10...60 |
| Protection |
IP 67 |
| Tests / approvals |
|
| EMC |
<table><tr><td>EN 60947-5-2</td><td></td></tr></table> |
| MTTF |
951 |
| Mechanical data |
|
| Weight |
134.5 |
| Dimensions |
60 x 10 x 83 |
| Side length X |
31 |
| Side length Y |
50 |
| Sensor width Z |
40.31 |
| Material |
housing: diecast zinc; lens: glass |
| Displays / operating elements |
|
| Display |
<table><tr><td>Switching status</td><td>1 x LED, yellow</td></tr><tr><td>Power</td><td>1 x LED, green</td></tr><tr><td>Function</td><td>1 x LED, yellow</td></tr></table> |
| Remarks |
|
| Pack quantity |
1 pcs. |
| Electrical connection |
|
| Connection |
Connector: 1 x M12; coding: A |
