| Type of light |
red light |
| System |
Function check output |
| Operating voltage |
10...35 DC; (cULus - Class 2 source required) |
| Current consumption |
< 45 |
| Protection class |
III |
| Reverse polarity protection |
yes |
| Type of light |
red light |
| Wave length |
660 |
| Electrical design |
PNP |
| Output function |
dark-on mode |
| Max. voltage drop switching output DC |
2 |
| Function check output |
yes |
| Permanent current rating of switching output DC |
200 |
| Switching frequency DC |
200 |
| Short-circuit protection |
yes |
| Type of short-circuit protection |
yes (non-latching) |
| Overload protection |
yes |
| Ambient temperature |
-10...60 |
| Protection |
IP 67 |
| EMC |
|
| MTTF |
919 |
| Weight |
150 |
| Dimensions |
65 x 10 x 106 |
| Side length X |
54 |
| Side length Y |
55 |
| Sensor width Z |
60.46 |
| Material |
housing: diecast zinc; lens: glass |
| Display |
| Switching status | 1 x LED, yellow | | Power | 1 x LED, green | | Function | 1 x LED, yellow |
|
| Pack quantity |
1 pcs. |
| Connection |
Connector: 1 x M12; coding: A |
