| Type of light |
Infrared light |
| Housing |
rectangular |
| Function principle |
Through-beam sensor |
| Operating voltage |
10...30 DC |
| Current consumption |
< 19 |
| Protection class |
III |
| Reverse polarity protection |
yes |
| Type of light |
Infrared light |
| Wave length |
880 |
| Overload protection |
yes |
| Transmitter / receiver |
transmitter |
| Range |
< 5 |
| Ambient temperature |
-25...60 |
| Protection |
IP 67 |
| EMC |
|
| MTTF |
1759 |
| Weight |
26.6 |
| Housing |
rectangular |
| Dimensions |
35 x 24 x 11 |
| Material |
housing: ABS; fixture: diecast zinc; LED window: SEPS; pushbutton: SEPS |
| Lens material |
|
| Lens alignment |
Front sensing |
| Display |
|
| Items supplied |
| Basic clip: 1, E20964 | | screws: 2 x (M3 x 16 mm) | | spring washers: 2 | | Nuts: 2 |
|
| Remarks |
| cULus - Class 2 source required |
|
| Pack quantity |
1 pcs. |
| Connection |
Connector: 1 x M8; coding: A |
