| Type of light |
red light |
| Housing |
rectangular |
| Function principle |
Through-beam sensor |
| Operating voltage |
10...30 DC |
| Current consumption |
< 19 |
| Protection class |
III |
| Reverse polarity protection |
yes |
| Type of light |
red light |
| Wave length |
660 |
| Overload protection |
yes |
| Transmitter / receiver |
transmitter |
| Range |
< 10 |
| Max. light spot diameter |
1000 |
| Light spot dimensions refer to |
at maximum range |
| Ambient temperature |
-25...60 |
| Protection |
IP 67 |
| EMC |
|
| MTTF |
1764 |
| Weight |
71.5 |
| Housing |
rectangular |
| Dimensions |
35 x 11 x 24 |
| Material |
housing: ABS; fixture: diecast zinc; LED window: SEPS; pushbutton: SEPS |
| Lens material |
|
| Lens alignment |
Side sensing |
| Display |
|
| Items supplied |
| screws: 2 x (M3 x 16 mm) | | Basic clip: 1, E20964 | | spring washers: 2 | | Nuts: 2 |
|
| Remarks |
| cULus - Class 2 source required |
|
| Pack quantity |
1 pcs. |
| Connection |
Cable: 2 m, PVC; 2 x 0.14 mm² |
