| Type of light |
red light |
| Housing |
Threaded type |
| Function principle |
Through-beam sensor |
| Operating voltage |
10...36 DC |
| Current consumption |
20 |
| Protection class |
II |
| Reverse polarity protection |
yes |
| Type of light |
red light |
| Wave length |
624 |
| Transmitter / receiver |
transmitter |
| Range |
< 25 |
| Max. light spot diameter |
1000 |
| Light spot dimensions refer to |
at maximum range |
| Ambient temperature |
-25...80 |
| Protection |
IP 67 |
| EMC |
|
| MTTF |
629 |
| Weight |
125.1 |
| Housing |
Threaded type |
| Dimensions |
M18 x 1 / L = 80.4 |
| Thread designation |
M18 x 1 |
| Material |
stainless steel (1.4404 / 316L); PA; EPDM |
| Lens material |
|
| Display |
|
| Items supplied |
|
| Remarks |
| cULus - Class 2 source required |
|
| Pack quantity |
1 pcs. |
| Connection |
Cable: 2 m, PUR; 3 x 0.34 mm² |
