| Type of light |
red light |
| Housing |
Threaded type |
| Function principle |
Diffuse reflection sensor |
| Operating voltage |
10...36 DC |
| Current consumption |
25 |
| Protection class |
II |
| Reverse polarity protection |
yes |
| Type of light |
red light |
| Electrical design |
PNP |
| Output function |
light-on/dark-on mode; (programmable) |
| Max. voltage drop switching output DC |
2.5 |
| Permanent current rating of switching output DC |
150; (200 (...60 °C)) |
| Switching frequency DC |
2000 |
| Short-circuit protection |
yes |
| Type of short-circuit protection |
yes (non-latching) |
| Overload protection |
yes |
| Range |
2...800; (white paper 200 x 200 mm 90 % remission) |
| Factory setting |
|
| Setting range |
150...800 |
| Range adjustable |
yes |
| Max. light spot diameter |
66 |
| Light spot dimensions refer to |
at maximum range |
| Ambient temperature |
-25...80 |
| Protection |
IP 65; IP 67; IP 68; IP 69K |
| EMC |
|
| MTTF |
473 |
| Weight |
255 |
| Housing |
Threaded type |
| Dimensions |
M18 x 1 / L = 80.4 |
| Thread designation |
M18 x 1 |
| Material |
stainless steel (1.4404 / 316L); PA; LCP; EPDM; TPU (urethane) |
| Lens material |
|
| Display |
| Switching status | 1 x LED, yellow |
|
| Teach function |
yes |
| Electronic lock |
yes |
| Items supplied |
|
| Remarks |
| cULus - Class 2 source required |
|
| Pack quantity |
1 pcs. |
| Connection |
Cable: 6 m, PVC; 3 x 0.34 mm² |
