| Type of light |
red light |
| Housing |
Threaded type |
| System |
polarization filter |
| Function principle |
Retro-reflective sensor |
| Operating voltage |
10...36 DC |
| Current consumption |
15 |
| Protection class |
II |
| Reverse polarity protection |
yes |
| Type of light |
red light |
| Electrical design |
PNP |
| Output function |
light-on mode |
| Max. voltage drop switching output DC |
2.5 |
| Permanent current rating of switching output DC |
150; (200 (...60 °C)) |
| Switching frequency DC |
1000 |
| Short-circuit protection |
yes |
| Type of short-circuit protection |
yes (non-latching) |
| Overload protection |
yes |
| Range referred to prismatic reflector |
0.03...4; (Prismatic reflector Ø 80 E20005) |
| Range adjustable |
no |
| Max. light spot diameter |
160 |
| Light spot dimensions refer to |
at maximum range |
| Polarization filter available |
yes |
| Ambient temperature |
-25...80 |
| Protection |
IP 65; IP 67; IP 68; IP 69K |
| EMC |
|
| MTTF |
500 |
| Weight |
257.5 |
| Housing |
Threaded type |
| Dimensions |
M18 x 1 / L = 68.6 |
| Thread designation |
M18 x 1 |
| Material |
housing: stainless steel (1.4404 / 316L); sealing: EPDM |
| Lens material |
|
| Display |
| Switching status | 1 x LED, yellow |
|
| Items supplied |
|
| Remarks |
| cULus - Class 2 source required |
|
| Pack quantity |
1 pcs. |
| Connection |
Cable: 6 m, PVC; 3 x 0.34 mm² |
