| Type of light |
red light |
| Housing |
rectangular |
| System |
Background suppression |
| Function principle |
Diffuse reflection sensor |
| Operating voltage |
10...30 DC |
| Current consumption |
20; ((24 V)) |
| Protection class |
III |
| Reverse polarity protection |
yes |
| Type of light |
red light |
| Wave length |
633 |
| Electrical design |
PNP |
| Output function |
light-on mode |
| Max. voltage drop switching output DC |
2.5 |
| Permanent current rating of switching output DC |
100 |
| Switching frequency DC |
750 |
| Short-circuit protection |
yes |
| Type of short-circuit protection |
yes (non-latching) |
| Range |
3...100; (white paper 200 x 200 mm) |
| Range on white object (90 % remission) |
3...100 |
| Range on grey object (18 % remission) |
6...80 |
| Range on black object (6 % remission) |
7...46 |
| Range adjustable |
no |
| Max. light spot diameter |
7 |
| Light spot dimensions refer to |
at maximum range |
| Background suppression available |
yes |
| Ambient temperature |
-25...60 |
| Protection |
IP 65 |
| EMC |
|
| MTTF |
1610 |
| Weight |
31.2 |
| Housing |
rectangular |
| Dimensions |
20.3 x 15 x 9 |
| Material |
PA |
| Lens material |
|
| Lens alignment |
Side sensing |
| Tightening torque |
0.5 |
| Display |
| Switching status | 1 x LED, yellow |
|
| Pack quantity |
1 pcs. |
| Connection |
Cable: 2 m, PUR; 3 x 0.14 mm² |
