| Type of light |
red light |
| Housing |
rectangular |
| Function principle |
Through-beam sensor |
| Operating voltage |
10...30 DC |
| Current consumption |
11; ((24 V)) |
| Protection class |
III |
| Type of light |
red light |
| Wave length |
633 |
| Transmitter / receiver |
transmitter |
| Range |
< 10 |
| Max. light spot diameter |
300 |
| Light spot dimensions refer to |
at maximum range |
| Ambient temperature |
-25...80 |
| Protection |
IP 65; IP 67; IP 68; IP 69K |
| EMC |
|
| MTTF |
2600 |
| UL approval |
| Ta | -25...40 °C | | Enclosure type | Type 1 | | voltage supply | Class 2 | | UL approval number | E002 |
|
| Weight |
33.7 |
| Housing |
rectangular |
| Dimensions |
34.8 x 13 x 21 |
| Material |
housing: stainless steel (1.4404 / 316L); plastics: PPSU; sealing: EPDM |
| Lens material |
|
| Lens alignment |
Side sensing |
| Tightening torque |
1; (screws) |
| Display |
|
| Remarks |
| cULus - Class 2 source required |
|
| Pack quantity |
1 pcs. |
| Connection |
Connector: 1 x M8; coding: A |
