| Type of light |
red light |
| Housing |
rectangular |
| System |
Background suppression |
| Function principle |
Diffuse reflection sensor |
| Application |
suited for use in the machine tool industry |
| Operating voltage |
10...30 DC |
| Current consumption |
22; ((24 V)) |
| Protection class |
III |
| Reverse polarity protection |
yes |
| Type of light |
red light |
| Wave length |
633 |
| Electrical design |
NPN |
| Output function |
light-on/dark-on mode; (selectable) |
| Max. voltage drop switching output DC |
2.5 |
| Permanent current rating of switching output DC |
100 |
| Switching frequency DC |
1000 |
| Short-circuit protection |
yes |
| Type of short-circuit protection |
yes (non-latching) |
| Range |
2...200; (white paper 200 x 200 mm) |
| Range on white object (90 % remission) |
2...200 |
| Range on grey object (18 % remission) |
4...200 |
| Range on black object (6 % remission) |
8...200 |
| Range adjustable |
yes |
| Max. light spot diameter |
8 |
| Light spot dimensions refer to |
at maximum range |
| Background suppression available |
yes |
| Ambient temperature |
-25...60 |
| Protection |
IP 65; IP 67; IP 68 |
| EMC |
|
| MTTF |
706 |
| UL approval |
| Ta | -25...40 °C | | Enclosure type | Type 1 | | voltage supply | Class 2 | | UL approval number | E001 |
|
| Weight |
33.9 |
| Housing |
rectangular |
| Dimensions |
41.3 x 13 x 21 |
| Material |
housing: stainless steel (1.4404 / 316L); plastics: PPSU; sealing: FKM |
| Lens material |
|
| Lens alignment |
Side sensing |
| Tightening torque |
1; (screws) |
| Display |
| Switching status | 1 x LED, yellow | | Power | 1 x LED, green |
|
| Remarks |
| cULus - Class 2 source required |
|
| Pack quantity |
1 pcs. |
| Connection |
Connector: 1 x M8; coding: A |
