| Type of light |
red light |
| Housing |
rectangular |
| System |
Background suppression |
| Function principle |
Diffuse reflection sensor |
| Operating voltage |
10...36 DC; (cULus - Class 2 source required) |
| Current consumption |
25 |
| Protection class |
II |
| Reverse polarity protection |
yes |
| Type of light |
red light |
| Electrical design |
PNP |
| Output function |
dark-on mode |
| Max. voltage drop switching output DC |
2.5 |
| Permanent current rating of switching output DC |
200 |
| Switching frequency DC |
1000 |
| Short-circuit protection |
yes |
| Type of short-circuit protection |
yes (non-latching) |
| Overload protection |
yes |
| Range |
50...1400; (white paper 200 x 200 mm 90 % remission) |
| Range on white object (90 % remission) |
50...1400 |
| Range on grey object (18 % remission) |
50...800 |
| Range on black object (6 % remission) |
50...550 |
| Range adjustable |
yes |
| Max. light spot diameter |
50 |
| Light spot dimensions refer to |
Range |
| Background suppression available |
yes |
| Ambient temperature |
-25...60 |
| Protection |
IP 65 |
| EMC |
|
| MTTF |
331 |
| Weight |
63 |
| Housing |
rectangular |
| Dimensions |
56 x 18.2 x 46.8 |
| Material |
housing: PA; Front framework: stainless steel; operator interface: TPE |
| Lens material |
|
| Lens alignment |
Side sensing |
| Display |
| Switching status | 1 x LED, yellow |
|
| Operating elements |
|
| Pack quantity |
1 pcs. |
| Connection |
Connector: 1 x M12; coding: A |
