| Laser protection class |
2 |
| Housing |
rectangular |
| System |
Background suppression |
| Operating voltage |
18...30 DC |
| Current consumption |
< 150 |
| Protection class |
III |
| Reverse polarity protection |
yes |
| Typ. lifetime |
50000 |
| Number of inputs and outputs |
Number of digital outputs: 1 |
| Total number of outputs |
1 |
| Electrical design |
NPN |
| Number of digital outputs |
1 |
| Output function |
normally open / closed; (programmable) |
| Max. current load per output |
200 |
| Short-circuit protection |
yes |
| Type of short-circuit protection |
yes (non-latching) |
| Overload protection |
yes |
| Max. light spot width |
15 |
| Max. light spot height |
15 |
| Light spot dimensions refer to |
10 m |
| Background suppression available |
yes |
| Background suppression |
10...100 |
| Measuring range |
0.2...10; (white paper 200 x 200 mm 90 % remission) |
| Sampling rate |
5 |
| Communication interface |
IO-Link |
| Transmission type |
COM2 (38,4 kBaud) |
| IO-Link revision |
1.1 |
| Profiles |
| Smart Sensor - SSP 0 | Generic Profiled Sensor | | Function | Device identification | | Function | Process data variable | | Function | Device diagnosis | | Function | Teach channel |
|
| SIO mode |
yes |
| Required master port class |
A |
| Process data analog |
2 |
| Process data binary |
1 |
| Min. process cycle time |
5 |
| Supported DeviceIDs |
| Type of operation | DeviceID |
|---|
| default | 807 |
|
| Ambient temperature |
-10...60 |
| Protection |
IP 67 |
| Laser protection class |
2 |
| Notes on laser protection |
| Caution: | Laser light | | Power: | <= 4,0 mW | | Wave length: | 650 nm | | pulse: | 1,3 ns | | Do not stare into beam. | | | Avoid exposure to the laser light. | | | laser class: | 2 | | EN / IEC60825-1:2007 | | EN / IEC60825-1:2014 | | Complies with 21 CFR 1040.10 except for conformance with IEC 60825-1 Ed. 3, as described in Laser Notice No. 56, dated May 8, 2019. |
|
| MTTF |
106 |
| Weight |
285.5 |
| Housing |
rectangular |
| Dimensions |
59 x 42 x 52 |
| Material |
housing: diecast zinc; front lens: glass; LED window: PC |
| Display |
| Switching status | LED, yellow | | Power | LED, green | | Distance, programming | alphanumeric display, 4-digit |
|
| Accessories (optional) |
|
| Remarks |
| cULus - Class 2 source required |
|
| Pack quantity |
1 pcs. |
| Connection |
Connector: 1 x M12; coding: A |
