| Application |
|
| Function principle |
Through-beam sensor |
| Application |
For use in industrial environments |
| Monitoring range |
|
| Range with fiber optic amplifier type |
OBF; OO50; OCF |
| OBF |
|
| Range of fiber optics |
100 |
| OO50 |
|
| Range of fiber optics |
250 |
| OCF (High Power) |
|
| Range of fiber optics |
1370 |
| Operating conditions |
|
| Ambient temperature |
-40...70 |
| Mechanical data |
|
| Weight |
48.5 |
| Version of sensing head |
angled |
| Sensing head height |
3 |
| Sensing head width |
8.5 |
| Sensing head length |
15 |
| Probe dimensions |
3 x 8.5 x 15 |
| Total length |
2000 |
| Min. bending radius |
2 |
| Core diameter |
1 |
| Fiber material |
PMMA |
| Fiber head material |
stainless steel (1.4305 / 303) |
| Fiber sheath material |
PE |
| Accessories |
|
| Items supplied |
<table><tr><td>Hexagon nuts: 4 x M2, stainless steel</td></tr></table> |
| Accessories (optional) |
<table><tr><td>Cutter for fibers:, E20600</td></tr></table> |
| Remarks |
|
| Pack quantity |
1 pcs. |
