| Type of light |
Infrared light |
| Housing |
rectangular |
| Operating voltage |
10...36 DC |
| Current consumption |
35; ((24 V)) |
| Protection class |
III |
| Reverse polarity protection |
yes |
| Type of light |
Infrared light |
| Wave length |
880 |
| Electrical design |
PNP |
| Output function |
light-on mode |
| Max. voltage drop switching output DC |
2.5 |
| Permanent current rating of switching output DC |
250 |
| Switching frequency DC |
100 |
| Short-circuit protection |
yes |
| Type of short-circuit protection |
yes (non-latching) |
| Overload protection |
yes |
| Range |
0...40; (Diffuse reflection sensor) |
| Range adjustable |
yes |
| Ambient temperature |
-25...80 |
| Protection |
IP 65 |
| EMC |
| EN 60947-5-2 | | | EN 55011 | class B |
|
| MTTF |
653 |
| Weight |
75.5 |
| Housing |
rectangular |
| Dimensions |
28 x 16 x 56 |
| Number of channels |
1 |
| Material |
PPO modified |
| Lens material |
|
| Display |
| Switching status | 1 x LED, yellow |
|
| Items supplied |
| Angle bracket: 1, E20211 | | screwdrivers |
|
| Remarks |
| light-on mode corresponds to the NC output function for through-beam fibers | | corresponds to the NO output function for diffuse-reflection fibers |
|
| Pack quantity |
1 pcs. |
| Connection |
Connector: 1 x M12; coding: A |
