| Type of light |
red light |
| Housing |
rectangular |
| System |
Function check output |
| Operating voltage |
12...36 DC |
| Current consumption |
50; ((24 V)) |
| Max. power consumption |
1.3 |
| Protection class |
III |
| Reverse polarity protection |
yes |
| Type of light |
red light |
| Wave length |
630 |
| Electrical design |
PNP |
| Output function |
light-on/dark-on mode; (programmable) |
| Max. voltage drop switching output DC |
2 |
| Function check output |
yes |
| Max. current load for function check output |
200 |
| Permanent current rating of switching output DC |
200 |
| Switching frequency DC |
800 |
| Notes on switching frequency |
|
| Short-circuit protection |
yes |
| Type of short-circuit protection |
yes (non-latching) |
| Overload protection |
yes |
| Time function |
0.001...0.1 |
| Range |
0...300; (Diffuse reflection sensor) |
| Range adjustable |
yes |
| Parameter setting options |
automatic and manual switch point setting; AND / OR logic functions; second switch point |
| Ambient temperature |
-20...60 |
| Protection |
IP 65 |
| EMC |
| EN 60947-5-2 | | | EN 55011 | class B |
|
| Weight |
556.5 |
| Housing |
rectangular |
| Dimensions |
76.5 x 105.4 x 70.7 |
| Number of channels |
8 |
| Fiber optic connection |
FE-11 / FT-11 |
| Material |
housing: ABS; display window: PMMA; LED window: SEPS; cover: diecast zinc plastic coated (PA) |
| Lens alignment |
Side sensing |
| Display |
| full graphic LCD display, rotation of the display by 180° possible language selection (German, English, French) | | Switching status | 8 x LED, yellow |
|
| Electronic lock |
yes |
| Items supplied |
| rail: 1 x 94 mm, EN 60715 |
|
| Remarks |
| cULus - Class 2 source required |
|
| Pack quantity |
1 pcs. |
| Connection |
Connector: 1 x M16 |
