| Output function |
2 x normally open; (potential-free) |
| Sensing range |
5; (with defined actuator) |
| Housing |
rectangular |
| Dimensions |
36 x 13 x 26 |
| Design |
coded target |
| Type of operation |
permanent operation |
| Operating voltage |
24 DC |
| Rated insulation voltage |
60 |
| Protection class |
III |
| Reverse polarity protection |
no |
| Internal resistance (Ri) |
10; (1 W) |
| Output function |
2 x normally open; (potential-free) |
| Permanent current rating of switching output DC |
50 |
| Switching frequency DC |
150 |
| Output data |
Interface type A |
| Short-circuit proof |
no |
| Max. capacitive load CL_max |
20 |
| Sensing range |
5; (with defined actuator) |
| Safe switching-off distance s(ar) |
15 |
| Response time to safety request |
10 |
| Max. fall time |
0.1 |
| Max. make time incl. bounce |
0.6 |
| Applications |
Class C to EN 60654-1 weatherproof application |
| Ambient temperature |
10...40 |
| Note on ambient temperature |
| operational life ≤ 175200 h |
|
| Max. relative air humidity |
briefly: 5...95 %; permanent: 5...70 % |
| Air pressure |
80...106 |
| Max. height above sea level |
2000 |
| Salt spray |
no |
| Protection |
IP 67; IP 69K |
| EMC |
|
| Shock resistance |
| EN 60068-2-27 | 30 g (11 ms) |
|
| Vibration resistance |
| IEC 60068-2-6 | 10 g (10...55 Hz) |
|
| MIssion time TM |
≤ 175200 |
| Mission time TM (additional indication) |
|
| B10D |
20.000.000; (without load; at max. load DC 12, 24 V, 50 mA: 400.000) |
| Weight |
114.5 |
| Housing |
rectangular |
| Mounting |
non-flush mountable |
| Dimensions |
36 x 13 x 26 |
| Material |
PA |
| Tightening torque |
0.8...2 |
| Items supplied |
| coded target | | cover caps: 4 |
|
| Remarks |
| In connection with a G150xS / AC4x2S type evaluation unit, it is possible to reach up to PL e (ISO 13849-1) or SIL cl 3 (IEC 62061) |
|
| Pack quantity |
1 pcs. |
| Connection |
Connector: 1 x M8; coding: A |
