| Number of inputs and outputs |
Number of digital outputs: 2 |
| Factory setting |
water-based media |
| Probe length L |
132 |
| System |
gold-plated contacts |
| Media |
Liquids |
| Dielectric constant of the medium |
> 1,8 |
| Recommended media |
water; water-based media; oils; oil-based media |
| Cannot be used for |
See operating instructions, chapter "Intended use". |
| Medium temperature |
-25...85 |
| Pressure rating |
|
| Vacuum resistance |
-500 |
| Operating voltage |
9.6...35 DC; (IO-Link: 18...30 DC) |
| Current consumption |
< 15 |
| Protection class |
III |
| Reverse polarity protection |
yes |
| Power-on delay time |
< 1 |
| Measuring principle |
capacitive |
| Number of inputs and outputs |
Number of digital outputs: 2 |
| Total number of outputs |
2 |
| Output signal |
switching signal; IO-Link |
| Electrical design |
PNP/NPN |
| Number of digital outputs |
2 |
| Output function |
normally open / closed; (configurable) |
| Max. voltage drop switching output DC |
2.5 |
| Permanent current rating of switching output DC |
100 |
| Short-circuit protection |
yes |
| Type of short-circuit protection |
yes (non-latching) |
| Overload protection |
yes |
| Factory setting |
water-based media |
| Probe length L |
132 |
| Active range A |
28 |
| Accuracy |
1,5 |
| Resolution |
0.1 |
| Dynamic response T09 |
240 |
| Response time |
< 0.3 |
| Communication interface |
IO-Link |
| Transmission type |
COM2 (38,4 kBaud) |
| IO-Link revision |
1.1 |
| SDCI standard |
IEC 61131-9 |
| Profiles |
| Common - I&D | Identification and Diagnosis | | Function | Measurement data, standard resolution |
|
| SIO mode |
yes |
| Required master port class |
A |
| Process data analog |
5 |
| Process data binary |
2 |
| Min. process cycle time |
4.5 |
| Supported DeviceIDs |
| Type of operation | DeviceID |
|---|
| default | 1053 |
|
| Ambient temperature |
-25...85 |
| Storage temperature |
-25...85 |
| Protection |
IP 68; IP 69K; (7 days / 3 m water depth / 0.3 bar: IP 68) |
| EMC |
| DIN EN 61000-6-2 | | | DIN EN 61000-6-3 | in a closed metal tank | | DIN EN 61000-6-4 | in plastic or open metal tanks |
|
| Shock resistance |
| DIN EN 60068-2-27 | 12 g (11 ms) |
|
| Vibration resistance |
| DIN EN 60068-2-6 | 5 g (10...2000 Hz) |
|
| MTTF |
433 |
| UL approval |
| UL approval number | H013 | | File number UL | E174191 |
|
| Weight |
203.55 |
| Material |
PP fiber-reinforced |
| Materials (wetted parts) |
PP |
| Probe diameter |
16 |
| Display |
| Power | LED, green | | Switching status | LED, yellow |
|
| Operating elements |
| inductive programming button | |
|
| Pack quantity |
1 pcs. |
| Connection |
Connector: 1 x M12; coding: A; Contacts: gold-plated |
