| Output function |
normally closed |
| Sensing range |
30...120 |
| Housing |
tubular |
| Dimensions |
Ø 164 / L = 63 |
| Frequency AC |
47...63 |
| Operating voltage |
90...250 AC |
| Protection class |
II |
| Reverse polarity protection |
no |
| Output function |
normally closed |
| Max. voltage drop switching output AC |
11 |
| Minimum load current |
15 |
| Max. leakage current |
6 |
| Permanent current rating of switching output AC |
200; (250 (...50 °C)) |
| Short-time current rating of switching output |
1500; (10 ms / 0,5 Hz) |
| Switching frequency AC |
3 |
| Short-circuit proof |
no |
| Overload protection |
no |
| Sensing range |
30...120 |
| Sensing range adjustable |
yes |
| Factory setting sensing range |
120 |
| Real sensing range Sr |
120 ± 10 % |
| Correction factor |
steel: 1 / stainless steel: 0.7 / brass: 0.4 / aluminum: 0.3 / copper: 0.2 |
| Hysteresis |
< 15 |
| Switch-point drift |
-15...15 |
| Ambient temperature |
-20...70 |
| Protection |
IP 65 |
| EMC |
|
| Weight |
1231 |
| Housing |
tubular |
| Mounting |
non-flush mountable |
| Dimensions |
Ø 164 / L = 63 |
| Material |
housing: PBT; bottom cover: aluminum |
| Display |
| Switching status | 1 x LED, yellow |
|
| Connection |
Cable: 2 m, PVC; 2 x 0.5 mm² |
| Remarks |
| Recommendation: check the unit for reliable function after a short circuit. |
|
| Pack quantity |
1 pcs. |
