| Electrical design |
PNP |
| Output function |
complementary |
| Sensing range |
20...70 |
| Housing |
tubular |
| Dimensions |
Ø 100 / L = 40 |
| Operating voltage |
10...36 DC |
| Current consumption |
20; (24 V) |
| Protection class |
II |
| Reverse polarity protection |
yes |
| Electrical design |
PNP |
| Output function |
complementary |
| Max. voltage drop switching output DC |
3.5 |
| Permanent current rating of switching output DC |
250 |
| Switching frequency DC |
5 |
| Short-circuit protection |
yes |
| Type of short-circuit protection |
yes (non-latching) |
| Overload protection |
yes |
| Sensing range |
20...70 |
| Sensing range adjustable |
yes |
| Factory setting sensing range |
70 |
| Real sensing range Sr |
70 ± 10 % |
| Correction factor |
steel: 1 / stainless steel: 0.7 / brass: 0.4 / aluminum: 0.4 / copper: 0.3 |
| Hysteresis |
< 15 |
| Switch-point drift |
-15...15 |
| Ambient temperature |
-20...70 |
| Protection |
IP 65 |
| EMC |
| EN 60947-5-2 | | | EN 55011 | class B |
|
| Weight |
508.5 |
| Housing |
tubular |
| Mounting |
non-flush mountable |
| Dimensions |
Ø 100 / L = 40 |
| Material |
PBT |
| Display |
| Switching status | 1 x LED, yellow |
|
| Items supplied |
| screws: 1 x (M10 x 50 mm) | | covers: 1 |
|
| Pack quantity |
1 pcs. |
| Connection |
Cable: 2 m, PVC; 4 x 0.34 mm² |
