| Electrical design |
PNP |
| Output function |
normally open |
| Sensing range |
5 |
| Housing |
Threaded type |
| Dimensions |
M18 x 1 / L = 70 |
| Application |
high-temperature applications |
| Operating voltage |
10...35 DC |
| Current consumption |
< 15 |
| Protection class |
III |
| Reverse polarity protection |
yes |
| Electrical design |
PNP |
| Output function |
normally open |
| Max. voltage drop switching output DC |
2 |
| Max. leakage current |
0.5 |
| Permanent current rating of switching output DC |
150 |
| Switching frequency DC |
400 |
| Short-circuit proof |
yes |
| Overload protection |
yes |
| Sensing range |
5 |
| Operating distance |
0...4.1 |
| Correction factor |
stainless steel: 0.6 / brass: 0.3 / aluminum: 0.2 / copper: 0.1 |
| Hysteresis |
3...15 |
| Switch-point drift |
-15...15 |
| Ambient temperature |
0...180 |
| Protection |
IP 65 |
| EMC |
| EN 61000-4-2 ESD | 2 kV CD / 4 kV AD | | EN 61000-4-3 HF radiated | 3 V/m | | EN 61000-4-4 Burst | 2 kV | | EN 61000-4-6 HF conducted | 3 V |
|
| MTTF |
682 |
| Weight |
263 |
| Housing |
Threaded type |
| Mounting |
flush mountable |
| Dimensions |
M18 x 1 / L = 70 |
| Thread designation |
M18 x 1 |
| Material |
threaded sleeve: stainless steel; sensing face: LCP |
| Items supplied |
|
| Pack quantity |
1 pcs. |
| Connection |
Cable: 5 m, silicone, Ø 5 mm; highly flexible; 3 x 0.22 mm² |
