Фото
Видео
Характеристики
| Connection | M12 Connector |
| Dimensions | 55 x 60 x 35 |
| Electrical design | AS-i |
| Ambient temperature | -20...70 |
Все характеристики
| Electrical design | AS-i | ||||
| Sensing range | 4 | ||||
| Housing | rectangular | ||||
| Dimensions | 55 x 60 x 35 | ||||
| Operating voltage | 26.5...31.6 DC; (cULus - Class 2 source required) | ||||
| Current consumption | < 40 | ||||
| Electrical design | AS-i | ||||
| Sensing range | 4 | ||||
| Ambient temperature | -20...70 | ||||
| Protection | IP 67 | ||||
| EMC |
|
||||
| MTTF | 924 | ||||
| AS-i version | 2.1 | ||||
| Extended addressing mode | yes | ||||
| AS-i I/O configuration | 0 | ||||
| AS-i ID code | A.F | ||||
| AS-i certificate | 74901 | ||||
| Weight | 149.5 | ||||
| Housing | rectangular | ||||
| Mounting | non-flush mountable | ||||
| Dimensions | 55 x 60 x 35 | ||||
| Material | PBT | ||||
| Display |
|
||||
| Items supplied |
|
||||
| Pack quantity | 1 pcs. |
Приемущества
| For monitoring valve positions |
| For reliable position feedback on valve actuators |
| Non-contact and self-cleaning system |
| Quick and secure mounting with only three screws |
| High shock and vibration resistance |
