| Housing |
Threaded type |
| Dimensions |
M30 x 1.5 / L = 70 |
| Operating voltage |
15...30 DC |
| Current consumption |
< 20 |
| Protection class |
II |
| Reverse polarity protection |
yes |
| Analog current output |
4...20; (linear; gradient: 1,143 mA/mm; for frontal approach and for target made of mild steel: 45 x 45 x 1 mm) |
| Max. load |
500 |
| Short-circuit protection |
yes |
| Overload protection |
yes |
| Measuring range |
1...15 |
| Correction factor |
steel: 1 / stainless steel: 0.7 / brass: 0.5 / aluminum: 0.4 / copper: 0.3 |
| Linearity error of analog output |
± 1 %; (of IA max) |
| Repeatability analog output |
± 1 %; (of IA max) |
| Response time |
< 20 |
| Ambient temperature |
-25...80 |
| Protection |
IP 67 |
| EMC |
|
| MTTF |
964 |
| Weight |
125.42 |
| Housing |
Threaded type |
| Mounting |
non-flush mountable |
| Dimensions |
M30 x 1.5 / L = 70 |
| Thread designation |
M30 x 1.5 |
| Material |
housing: brass white bronze coated; sensing face: PBT |
| Tightening torque |
50 |
| Display |
| within the operating range | 1 x LED, yellow lights | | outside the operating range | 1 x LED, yellow flashing |
|
| Items supplied |
|
| Pack quantity |
1 pcs. |
| Connection |
Connector: 1 x M12; coding: A |
