| Housing |
Threaded type |
| Dimensions |
M18 x 1 / L = 54 |
| Operating voltage |
15...30 DC |
| Current consumption |
< 20 |
| Protection class |
II |
| Reverse polarity protection |
yes |
| Analog current output |
4...20; (linear; gradient: 2,22 mA/mm; for frontal approach and for target made of mild steel: 24 x 24 x 1 mm) |
| Max. load |
500 |
| Short-circuit protection |
yes |
| Overload protection |
yes |
| Measuring range |
0.8...8 |
| Correction factor |
steel: 1 / stainless steel: 0.7 / brass: 0.5 / aluminum: 0.4 / copper: 0.3 |
| Linearity error of analog output |
± 1 %; (of IA max) |
| Repeatability analog output |
± 1 %; (of IA max) |
| Response time |
< 10 |
| Ambient temperature |
-40...80 |
| Protection |
IP 67 |
| MTTF |
952 |
| Weight |
79.06 |
| Housing |
Threaded type |
| Mounting |
non-flush mountable |
| Dimensions |
M18 x 1 / L = 54 |
| Thread designation |
M18 x 1 |
| Material |
housing: brass white bronze coated; sensing face: PBT |
| Display |
| target in measuring range | yellow lights | | target outside measuring range | yellow flashing |
|
| Items supplied |
|
| Pack quantity |
1 pcs. |
| Connection |
Cable: 0.2 m, PUR, Ø 4 mm; burning behaviour to ECE R118 rev. 2; 3 x 0.50 mm² |
