| Product characteristics |
|
| Number of inputs and outputs |
Number of digital outputs: 1 |
| Process connection |
threaded connection G 1 external thread Aseptoflex Vario |
| Application |
|
| System |
gold-plated contacts |
| Application |
hygienic systems |
| Medium temperature |
-25...95; (for SIP process: ...140 °C) |
| Pressure rating |
<table><tr><td>30 bar</td><td>3 MPa</td></tr></table> |
| MAWP (for applications according to CRN) |
30 |
| Electrical data |
|
| Operating voltage |
19...36 DC |
| Current consumption |
< 60 |
| Protection class |
III |
| Reverse polarity protection |
yes |
| Power-on delay time |
10 |
| Inputs / outputs |
|
| Number of inputs and outputs |
Number of digital outputs: 1 |
| Outputs |
|
| Total number of outputs |
1 |
| Output signal |
switching signal |
| Electrical design |
PNP |
| Number of digital outputs |
1 |
| Output function |
normally open / closed; (configurable) |
| Max. voltage drop switching output DC |
2.5 |
| Permanent current rating of switching output DC |
250 |
| Short-circuit protection |
yes |
| Type of short-circuit protection |
yes (non-latching) |
| Overload protection |
yes |
| Measuring/setting range |
|
| Probe length L |
55 |
| Liquids |
|
| Setting range |
3...300 |
| Greatest sensitivity |
3...100 |
| Gases |
|
| Setting range |
200...3000 |
| Greatest sensitivity |
200...800 |
| Accuracy / deviations |
|
| Repeatability |
1...5 |
| Note on repeatability |
<table><tr><td>for water 5...100 cm/s; 25 °C</td></tr><tr><td>Factory setting </td></tr></table> |
| Temperature drift |
0.1; (for water 5...100 cm/s; 10...70 °C) |
| Max. temperature gradient of medium |
300 |
| Switch point accuracy |
± 2...± 10; (for water 5...100 cm/s; 25 °C; Factory setting) |
| Hysteresis |
2...5; (for water 5...100 cm/s; 25 °C; Factory setting) |
| Reaction times |
|
| Response time |
1...10 |
| Software / programming |
|
| Adjustment of the switch point |
pushbuttons |
| Operating conditions |
|
| Ambient temperature |
-25...60 |
| Protection |
IP 67; IP 69K |
| Tests / approvals |
|
| EMC |
<table><tr><td>DIN EN 61000-6-2</td><td></td></tr><tr><td>DIN EN 61000-6-3</td><td></td></tr></table> |
| Shock resistance |
<table><tr><td>DIN EN 60068-2-27</td><td>50 g (11 ms)</td></tr></table> |
| Vibration resistance |
<table><tr><td>DIN EN 60068-2-6</td><td>10 g (55...2000 Hz)</td></tr></table> |
| MTTF |
298 |
| Mechanical data |
|
| Weight |
440 |
| Housing |
tubular |
| Dimensions |
Ø 50 / L = 154 |
| Material |
stainless steel (1.4404 / 316L); PC; PBT-GF20; EPDM/X; sealing: FKM |
| Materials (wetted parts) |
stainless steel (1.4435 / 316L) surface characteristics: Ra < 0,4 µm / Rz = 4 µm |
| Process connection |
threaded connection G 1 external thread Aseptoflex Vario |
| Probe diameter |
7.7 |
| Installation length EL |
55 |
| Displays / operating elements |
|
| Display |
<table><tr><td>Function</td><td>10 x LED, three-color</td></tr></table> |
| Remarks |
|
| Pack quantity |
1 pcs. |
| Electrical connection |
|
| Connection |
Connector: 1 x M12; coding: A; Contacts: gold-plated |
