| Number of inputs and outputs |
Number of digital outputs: 1 |
| Process connection |
threaded connection M18 x 1,5 Internal thread |
| Media |
Liquids; Gases |
| Medium temperature |
-25...80 |
| Pressure rating |
|
| MAWP (for applications according to CRN) |
208 |
| Response time |
1...10 |
| Response time |
1...10 |
| Frequency AC |
47...63 |
| Operating voltage tolerance |
-15...10 |
| Operating voltage |
90...240 AC |
| Max. power consumption |
3.5 |
| Protection class |
II |
| Reverse polarity protection |
no |
| Power-on delay time |
10 |
| Number of inputs and outputs |
Number of digital outputs: 1 |
| Total number of outputs |
1 |
| Output signal |
switching signal |
| Electrical design |
Relay |
| Number of digital outputs |
1 |
| Output function |
normally open / closed; (configurable) |
| Contact rating |
3 A (250 V AC / 30 V DC); (number of switching cycles: 20 million mechanically; switching cycles at 3 A load: 100,000 electrical; type of switch-off: normally open) |
| Short-circuit proof |
no |
| Overload protection |
no |
| Probe length L |
45 |
| Repeatability |
1...5 |
| Note on repeatability |
| for water 5...100 cm/s; 25 °C | | Factory setting |
|
| Temperature drift |
0.1; (for water 5...100 cm/s; 10...70 °C) |
| Max. temperature gradient of medium |
300 |
| Switch point accuracy |
± 2...± 10; (for water 5...100 cm/s; 25 °C; Factory setting) |
| Hysteresis |
2...5; (for water 5...100 cm/s; 25 °C; Factory setting) |
| Response time |
1...10 |
| Adjustment of the switch point |
pushbuttons |
| Ambient temperature |
-25...80 |
| Storage temperature |
-25...100 |
| Protection |
IP 67 |
| EMC |
| DIN EN 61000-6-2 | | | DIN EN 61000-6-3 | |
|
| Shock resistance |
| DIN EN 60068-2-27 | 50 g (11 ms) |
|
| Vibration resistance |
| DIN EN 60068-2-6 | 18 g (55...2000 Hz) |
|
| MTTF |
221 |
| Weight |
262.5 |
| Housing |
tubular |
| Dimensions |
Ø 50 / L = 113 |
| Material |
stainless steel (1.4404 / 316L); stainless steel (1.4301 / 304); PC; PBT-GF20; EPDM/X |
| Materials (wetted parts) |
stainless steel (1.4404 / 316L); O-ring: FKM 80 Shore A |
| Process connection |
threaded connection M18 x 1,5 Internal thread |
| Probe diameter |
8.2 |
| Installation length EL |
45 |
| Display |
| Function | 10 x LED, three-color |
|
| Connection |
Connector: 1 x 1/2"; coding: C |
| Remarks |
| Recommendation Check the safe functioning of the unit after a short circuit. |
|
| Pack quantity |
1 pcs. |
